株式会社YUEI CASTER Product Information

J SERIES: These series are mainly used for a platform carrier transporting a heavy articles
and widely used for general industries.
PM SERIES: These series are casters that are newly developed to support towing.
In comparison with J series, these casters provide excellent life span,
traveling performance and operability.
J2 SERIES: These are casters having standard size of roll box pallet that are widely used
for a platform carrier, roll box pallet and other industries.
RJ2 SERIES: These are casters having standard size of roll box pallet that are widely used for a platform carrier, roll box pallet and other industries.
These are casters that are light and provide excellent cost performance in comparison with J2 series, which were realized by simplifying the structure of J2series.
SJ SERIES: These series are mainly used for a platform carrier for transporting medium
load and widely used for general industries.

J SERIES

These series are mainly used for a platform carrier transporting a heavy articles and widely used for general industries.

J TYPE

Swivel (Double bearing)Plate Type

Wheel diameter:φ75～φ200
Allowance load:80～400(daN)

JB TYPE

Equipped with a lever type double stopper

Swivel (Double bearing)Plate Type

Wheel diameter:φ75～φ200
Allowance load:80～400(daN)

JB TYPE

Equipped with a pedal type double stopper

Swivel (Double bearing)Plate Type

Wheel diameter:φ100～φ150
Allowance load:100～300(daN)

J-S TYPE

Equipped with a pedal type single stopper

Swivel (Double bearing)Plate Type

Wheel diameter:φ100～φ200
Allowance load:100～400(daN)

K TYPE

Fixed wheel Plate Type

Wheel diameter:φ75～φ200
Allowance load:80～400(daN)

KB TYPE

Equipped with a lever type single stopper

Fixed wheel Plate Type

Wheel diameter:φ100～φ200
Allowance load:100～400(daN)

JK TYPE

Spirally fixing type

Swivel(Spirally fixing type)(Double bearing)Plate Type

Wheel diameter:φ150
Standard load:200～300(daN)

JK-S TYPE

Equipped with a pedal type single stopper

Spirally fixing type

Wheel diameter:φ150
Standard load:200～300(daN)

PM SERIES

These series are casters that are newly developed to support towing. In comparison with J series, these casters provide excellent life span, traveling performance and operability.

PMS TYPE

Swivel (Double bearing)Plate Type

Wheel diameter:φ130～200
Allowance load:180～400(daN)

PMS-LB TYPE

Equipped with a lever type double stopper

Swivel (Double bearing)Plate Type

Wheel diameter:φ130～200
Allowance load:180～400(daN)

PMR TYPE

Fixed wheel Plate Type

Wheel diameter:φ130～200
Allowance load:180～400(daN)

J2 SERIES

These are casters having standard size of roll box pallet that are widely used for a platform carrier, roll box pallet and other industries.

J2 TYPE

Swivel (Double bearing)Plate Type

Wheel diameter:φ130～φ150
Allowance load:150～180(daN)

J2-S TYPE

Equipped with a pedal type single stopper

Swivel (Double bearing)Plate Type

Wheel diameter:φ130～φ150
Allowance load:150～180(daN)

K2 TYPE

Fixed wheel Plate Type

Wheel diameter:φ130～φ150
Allowance load:150～180(daN)

J2K TYPE

Spirally fixing type

Swivel(Spirally fixing type)(Double bearing)Plate Type

Wheel diameter:φ130～φ150
Standard load:150～180(daN)

J2K-S TYPE

Equipped with a pedal type single stopper

Spirally fixing type

Swivel(Spirally fixing type)(Double bearing)Plate Type

Wheel diameter:φ130～φ150
Standard load:150～180(daN)

RJ2 SERIES

These are casters having standard size of roll box pallet that are widely used for a platform carrier, roll box pallet and other industries. These are casters that are light and provide excellent cost performance in comparison with J2 series, which were realized by simplifying the structure of J2series.
